Our lathe series, such as the C6163 model, features a maximum rotating diameter of 630MM, making it easy to handle large workpiece machining; the maximum machining length is 3000MM, meeting the requirements for machining long shaft parts; the speed range is 10 – 800 RPM, allowing for flexible speed adjustments to accommodate different materials and machining processes; the spindle through-hole diameter is 73MM, facilitating the passage of bars and other materials, enhancing machining efficiency.nnThe CNC lathe CAK6150B, with the system model Guangshu 980TB2, has a maximum machining length of 1000MM, a maximum machining diameter of 500MM, and a maximum turning diameter of 500MM as well, ensuring precise machining of various parts; the spindle speed range is four-gear variable speed from 40 to 1800 RPM, providing stable power output under different working conditions; the spindle through-hole diameter is 74MM, with 4 tool positions, machining accuracy can reach 0.01MM, and it is equipped with a non-hydraulic tailstock and a hydraulic chuck configuration, providing a guarantee for efficient and precise machining.nnFor milling machine products, taking the multi-functional end face milling machine as an example, there are various specifications and models available. For instance, the DX30 – 15W model, the machine bed size is 5000×1060×480mm, with a sturdy and rigid structure, capable of adapting to the plane and end face groove milling of large and extra-large workpieces. The longitudinal travel is 3100mm, the cross travel of the beam is 1500mm, the beam lift travel is 1500mm, the end face milling横向伸出行程 is 250mm, and the end face lift travel is 1500mm, allowing for free adjustment of machining height according to the size of the workpiece, meeting diverse machining needs. The beam milling head power is 4kw, the end face milling head power is 5.5kw, the milling cutter head speed is between 88 – 628rpm, the recommended maximum cutter diameter is φ200, and the beam vertical milling head swiveling angle is ±30°, enabling multi-angle milling operations.nnThe small-scale hard rail CNC milling machine TK – 650 also has significant advantages. The maximum values for the X/Y/Z axes are 650/450/450mm respectively, the distance from the spindle nose to the worktable surface is between 150 – 650mm, and the distance from the spindle center to the column surface is 540mm; the worktable size is 800×450mm, capable of withstanding a maximum weight of 400kg, the T-slot dimensions (center distance x slot width x number of slots) are 80×18×5mm. The spindle taper is BT40, with a speed of 8000rpm,采用皮带传动, spindle motor power is 5.5kw; the cooling system has a coolant axial motor of 1.5kw. In terms of feed rate, the rapid traverse of the x, y, z axes can reach 18/24 m/min, and the maximum cutting value is 6000 mm/min. The positioning accuracy can reach ±0.005mm, and the repeat positioning accuracy is 0.003mm, ensuring high machining precision.
